Slit Type

Image Flexible Couplings - Spiral Slit Type Flexible Couplings - Slit Type - Set Screw Type Flexible Couplings - Slit Type - Clamping Type Flexible Couplings - Slit Type - Set Screw Type Flexible Couplings - Slit Type - Clamping Type Flexible Couplings - Slit Type - Set Screw Type Flexible Couplings - Slit Type - Clamping Type Flexible Couplings - Slit Type - Set Screw + Key Type Flexible Couplings - Slit Type - Set Screw + Key Type
Part Name Flexible Couplings - Spiral Slit Type Flexible Couplings - Slit Type - Set Screw Type Flexible Couplings - Slit Type - Clamping Type Flexible Couplings - Slit Type - Set Screw Type Flexible Couplings - Slit Type - Clamping Type Flexible Couplings - Slit Type - Set Screw Type Flexible Couplings - Slit Type - Clamping Type Flexible Couplings - Slit Type - Set Screw + Key Type Flexible Couplings - Slit Type - Set Screw + Key Type
Part Number MSH MSX MSX-C MST MST-C MSTS MSTS-C MST-K MSTS-K
Feature Single-Piece Construction
Zero Backlash
Low reaction force
Single-Piece
Construction
Zero Backlash
High Torsional
Stiffness
Single-Piece
Construction
Zero Backlash
High Torsional
Stiffness
Single-Piece
Construction
Zero Backlash
Single-Piece
Construction
Zero Backlash
Single-Piece
Construction
Zero Backlash
High Torsional
Stiffness
Single-Piece
Construction
Zero Backlash
High Torsional
Stiffness
Single-Piece
Construction
Zero Backlash
Single-Piece
Construction
Zero Backlash
Size Standard Standard Standard Standard Standard Standard Standard Standard Standard
Hub Material Aluminum Alloy Aluminum Alloy Aluminum Alloy Aluminum Alloy Aluminum Alloy Stainless Steel Stainless Steel Aluminum Alloy Stainless Steel
Shaft Fastening Method Clamping Set Screw Clamping Set Screw Clamping Set Screw Clamping Set Screw + Key Set Screw + Key
Diameter φ8 ~ φ32 φ16 ~ φ44 φ16 ~ φ44 φ8 ~ φ63 φ12 ~ φ63 φ8 ~ φ63 φ12 ~ φ63 φ32 ~ φ63 φ32 ~ φ63
Torque - 0.5N・m ~ 9N・m 0.5N・m ~ 9N・m 0.1N・m ~ 32N・m 0.4N・m ~ 32N・m 0.2N・m ~ 35N・m 0.3N・m ~ 35N・m 4N・m ~ 32N・m 3.5N・m ~ 35N・m
CAD CAD CAD CAD CAD CAD CAD CAD CAD CAD
Specifications Specifications Specifications Specifications Specifications Specifications Specifications Specifications Specifications Specifications
List MSH-13C MSH-16C MSH-20C MSH-26C MSH-32C MSH-8 MSX-16 MSX-19 MSX-24 MSX-29 MSX-34 MSX-39 MSX-44 MSX-16C MSX-19C MSX-24C MSX-29C MSX-34C MSX-39C MSX-44C MST-12 MST-16 MST-20 MST-25 MST-32 MST-40 MST-50 MST-63 MST-8 MST-12C MST-16C MST-20C MST-25C MST-32C MST-40C MST-50C MST-63C MSTS-12 MSTS-16 MSTS-20 MSTS-25 MSTS-32 MSTS-40 MSTS-50 MSTS-63 MSTS-8 MSTS-12C MSTS-16C MSTS-20C MSTS-25C MSTS-32C MSTS-40C MSTS-50C MSTS-63C MST-32K MST-40K MST-50K MST-63K MSTS-32K MSTS-40K MSTS-50K MSTS-63K
Image Flexible Couplings - Slit Type - Set Screw Type Flexible Couplings - Slit Type - Set Screw Type Flexible Couplings - Slit Type - Clamping Type Flexible Couplings - Slit Type - Clamping Type Cleanroom / Vacuum / Heat Resistant Couplings - Slit Type (SUS316L) - Clamping Type Cleanroom / Vacuum / Heat Resistant Couplings - Slit Type (SUS316L) - Clamping Type Cleanroom / Vacuum / Heat Resistant Couplings - Slit Type (PEEK) - Clamping Type Coupling for Vacuum Variable Capacitor - Slit Type (PEEK) - Clamping Type
Part Name Flexible Couplings - Slit Type - Set Screw Type Flexible Couplings - Slit Type - Set Screw Type Flexible Couplings - Slit Type - Clamping Type Flexible Couplings - Slit Type - Clamping Type Cleanroom / Vacuum / Heat Resistant Couplings - Slit Type (SUS316L) - Clamping Type Cleanroom / Vacuum / Heat Resistant Couplings - Slit Type (SUS316L) - Clamping Type Cleanroom / Vacuum / Heat Resistant Couplings - Slit Type (PEEK) - Clamping Type Coupling for Vacuum Variable Capacitor - Slit Type (PEEK) - Clamping Type
Part Number MWS MWSS MWS-C MWSS-C XSTS-C XWSS-C MSXP-C MSXP-C-W-SP
Feature Single-Piece
Construction
Zero Backlash
Low Inertia
Single-Piece
Construction
Zero Backlash
High Torque
Single-Piece
Construction
Zero Backlash
Low Inertia
Single-Piece
Construction
Zero Backlash
High Torque
Clean
Low Particle
Chemical Resistance
Clean
Low Particle
Chemical Resistance
PEEK
Low Outgas
Coupling for Vacuum Variable Capacitor
Size Short Short Short Short Standard Short Standard Long
Hub Material Aluminum Alloy Stainless Steel Aluminum Alloy Stainless Steel SUS316L SUS316L PEEK PEEK
Shaft Fastening Method Set Screw Set Screw Clamping Clamping Clamping Clamping Clamping Clamping
Diameter φ8 ~ φ32 φ8 ~ φ32 φ12 ~ φ32 φ12 ~ φ32 φ25 ~ φ63 φ25 ~ φ32 φ25 ~ φ36 φ25
Torque 0.1N・m ~ 4N・m 0.2N・m ~ 3.5N・m 0.4N・m ~ 4N・m 0.3N・m ~ 3.5N・m 2N・m ~ 35N・m 2N・m ~ 3.5N・m 0.7N・m ~ 1.5N・m 1.3N・m
CAD CAD CAD CAD CAD CAD CAD CAD CAD
Specifications Specifications Specifications Specifications Specifications Specifications Specifications Specifications Specifications
List MWS-12 MWS-16 MWS-20 MWS-25 MWS-32 MWS-8 MWSS-12 MWSS-16 MWSS-20 MWSS-25 MWSS-32 MWSS-8 MWS-12C MWS-16C MWS-20C MWS-25C MWS-32C MWSS-12C MWSS-16C MWSS-20C MWSS-25C MWSS-32C XSTS-25C XSTS-32C XSTS-40C XSTS-50C XSTS-63C XWSS-25C XWSS-32C MSXP-25C MSXP-30C MSXP-36C MSXP-25C-W40

Related products

Image Photo Sensor Flange Damper Rolls
Part Name Photo Sensor Flange Damper Rolls
Part Number MPF MDR
Feature Photo Sensor Flange Damper for Stepping Motor
Material - -
CAD CAD CAD
Specifications Specifications Specifications
List MPF-32 MPF-40 MPF-50 MDR-41 MDR-52 MDR-57
